Audia
Configurable Audio DSP.

AudiaFLEX
AudiaFLEX
With AudiaFLEX, you can choose any configuration of input and output that suits your specific system—no compromise required. Distribute multi-channel audio seamlessly among multiple units via CobraNet using Cat-5 cable, and control the entire network's processing power over Ethernet.
- Up to 24 inputs/outputs, in any combination of channel pairs by card type, including wideband AEC inputs
- Optional CobraNet® module
- On-screen display of the total audio design
- Configuration/control via PC/laptop
- Third-party control via RS-232
- Remote control panels for level, presets, etc.
- Built-in diagnostic tools
- Remote function control via Ethernet
- Event scheduling
With AudiaFLEX, you can choose any configuration of input and output that suits your specific system—no compromise required. Distribute multi-channel audio seamlessly among multiple units via CobraNet using Cat-5 cable, and control the entire network's processing power over Ethernet.
- Up to 24 inputs/outputs, in any combination of channel pairs by card type, including wideband AEC inputs
- Optional CobraNet® module
- On-screen display of the total audio design
- Configuration/control via PC/laptop
- Third-party control via RS-232
- Remote control panels for level, presets, etc.
- Built-in diagnostic tools
- Remote function control via Ethernet
- Event scheduling
Additional Information
For more design guides, visit our interactive design guides website.
Configurable Audio DSP Cards.
AEC-2HD Dual-Channel Wideband Acoustic Echo Cancellation Input Cards
- Two channels of acoustic echo cancellation and background noise reduction
- Dedicated wideband processing on each input
- Includes AEC technology delivering true 20Hz to 20kHz wideband AEC, tail length up to 300ms, and a convergence rate up to 100dB/second
- On-board DSP, does not use AudiaFLEX resources
Dual-Channel Mic/Line Input Cards
- Each card provides 2 mic/line input channels
- Balanced inputs on plug-in barrier strip connectors
- 0~66dB gain range for microphone or line sources
Dual-Channel Mic/Line Output Cards
- Each card provides 2 mic/line output channels
- Balanced outs on plug-in barrier strip connectors
- -100~+12dB level fader range for volume control
- Selectable ref level for best interface/performance
Dual-Channel Power Amplifier Cards
- Directly powers 4, 6, or 8Ω speakers
- Software configurable from 5 to 30 watts dual-channel and from 10 to 60 watts mono-bridged
- Upgraded AudiaFLEX power supply provides 120 watts of power, for up to twelve PA-2 cards
Dual-Channel Telephone Interface Cards
- Initiate outgoing calls including: DTMF tone dialing, speed-dialing, redial, flash
- Detect and answer incoming calls
- Line-echo cancellation
- Continuous line-status and fault monitoring
Dual-Channel Voice Over Internet Protocol Cards
- Two channels of VoIP interface per card
- Enables conferencing over VoIP directly from AudiaFLEX
- Caller ID, SIP Protocol, auto-answer, speed dial, hold capability, and direct dialing on each line
- Create redundancies within a conferencing system when combined with the TI-2 Card and/or CODEC
- Up to 6 VoIP-2 Cards can be installed into a single AudiaFLEX unit
