Matrix Systems.


AC12.8SET

AC12.8SET

Product is not available for sale in the US or Canada

AC12.8SET is an AUDIOCONTROL12.8 with the AC12.8FP feature pack already built in. The AUDIOCONTROL12.8 matrix controls much more than your audio. You can have different sound sources in different zones at various volume levels, do selective paging and on top of that control other devices as well. Your all in one audio and control center.

The Feature Pack expands the functionalities of the AUDIOCONTROL with message player/recorder, logical inputs & 0-10V inputs, logic outputs, output delay and zone combining.

Product is not available for sale in the US or Canada

AC12.8SET is an AUDIOCONTROL12.8 with the AC12.8FP feature pack already built in. The AUDIOCONTROL12.8 matrix controls much more than your audio. You can have different sound sources in different zones at various volume levels, do selective paging and on top of that control other devices as well. Your all in one audio and control center.

The Feature Pack expands the functionalities of the AUDIOCONTROL with message player/recorder, logical inputs & 0-10V inputs, logic outputs, output delay and zone combining.


AUDIOCONTROL12.8

AUDIOCONTROL12.8

Product is not available for sale in the US or Canada

AUDIOCONTROL12.8 is a DSP powered audio matrix for small and medium sized audio applications, featuring advanced control of audio processing and routing with control of other (non-audio) devices which is unique on the market. The audio matrix system has 12 inputs, 8 line outputs and a digital stereo SPDIF input and output. There are 3 serial ports (one on the front and two on the rear of the unit) to configure the unit and to control external devices. The AUDIOCONTROL12.8 uses a fixed architecture DSP platform meaning that the audio path has the same fixed flow for all inputs and outputs.

The integrated real time task scheduler can perform a variety of tasks that means the AUDIOCONTROL12.8 is suitable for many projects. Up to 120 addressable/programmable paging microphones/extenders can be connected, each with their own functionality and individual presets and up to 8 priority levels.

Product is not available for sale in the US or Canada

AUDIOCONTROL12.8 is a DSP powered audio matrix for small and medium sized audio applications, featuring advanced control of audio processing and routing with control of other (non-audio) devices which is unique on the market. The audio matrix system has 12 inputs, 8 line outputs and a digital stereo SPDIF input and output. There are 3 serial ports (one on the front and two on the rear of the unit) to configure the unit and to control external devices. The AUDIOCONTROL12.8 uses a fixed architecture DSP platform meaning that the audio path has the same fixed flow for all inputs and outputs.

The integrated real time task scheduler can perform a variety of tasks that means the AUDIOCONTROL12.8 is suitable for many projects. Up to 120 addressable/programmable paging microphones/extenders can be connected, each with their own functionality and individual presets and up to 8 priority levels.


AUDIOSYSTEM8.8

AUDIOSYSTEM8.8

Product is not available for sale in the US or Canada

Although it can look quite simple, a small multi-zone installation is not always an easy or small job for the installer. He needs to install and connect many electronic units (sources, amplifiers, wall panels, and more) in order to provide the perfect audio solution for his customer. With the AUDIOSYSTEM8.8 the installer now can propose a complete audio system to his customers that covers many small or medium sized applications with just one unit.

The AUDIOSYSTEM8.8 audio matrix has 8 speaker outputs (4 stereo or 8 mono zones) with each a built-in 30 watts digital amplifier and also has 4 additional line outputs. The unit has 4 FM radios built-in and it has 4/8 stereo/mono line inputs. Out of the box the AUDIOSYSTEM8.8 is configured with 4 stereo inputs en 4 stereo output zones.

Product is not available for sale in the US or Canada

Although it can look quite simple, a small multi-zone installation is not always an easy or small job for the installer. He needs to install and connect many electronic units (sources, amplifiers, wall panels, and more) in order to provide the perfect audio solution for his customer. With the AUDIOSYSTEM8.8 the installer now can propose a complete audio system to his customers that covers many small or medium sized applications with just one unit.

The AUDIOSYSTEM8.8 audio matrix has 8 speaker outputs (4 stereo or 8 mono zones) with each a built-in 30 watts digital amplifier and also has 4 additional line outputs. The unit has 4 FM radios built-in and it has 4/8 stereo/mono line inputs. Out of the box the AUDIOSYSTEM8.8 is configured with 4 stereo inputs en 4 stereo output zones.


ZONE4

ZONE4

Product is not available for sale in the US or Canada

The sophisticated pre-amplifier ZONE4 allows you to control four stereo zones with just one affordable unit. In any of the 4 zones you can play music that comes from one of the 4 music sources you can connect.

There is also the possibility to assign 3 microphones to each zone where MIC1 can be a dynamic priority mic (via contact closure) or a 4-zone selective paging microphone (MICPAT-4). Each signal is assignable to any of the four output zones through dipswitches on the front and the back of the unit. Phantom power supply on MIC 1 & 2 can be activated via a dip switch.

The ZONE4 can be controlled from the front panel (with digital display), via the RS232-connector or via the IR serial. On top of that you can control the unit via the ZONE4R remote control panels. These control panels have a clear LED status display and buttons for music level, MIC/MIX level, source select and mute controls. Because the remote is wired with a normal CAT5 cable, it is very easy to install.

On the output side, there is a line input selector and music level control per zone. A clear digital display makes it easier to monitor the functioning of the unit. Further, there are independent MIC-MIX level control and bass-treble control per zone.

The unit is 19” format and comes standard with removable brackets. The removable metal cover (included) protects your MIC-settings.

Product is not available for sale in the US or Canada

The sophisticated pre-amplifier ZONE4 allows you to control four stereo zones with just one affordable unit. In any of the 4 zones you can play music that comes from one of the 4 music sources you can connect.

There is also the possibility to assign 3 microphones to each zone where MIC1 can be a dynamic priority mic (via contact closure) or a 4-zone selective paging microphone (MICPAT-4). Each signal is assignable to any of the four output zones through dipswitches on the front and the back of the unit. Phantom power supply on MIC 1 & 2 can be activated via a dip switch.

The ZONE4 can be controlled from the front panel (with digital display), via the RS232-connector or via the IR serial. On top of that you can control the unit via the ZONE4R remote control panels. These control panels have a clear LED status display and buttons for music level, MIC/MIX level, source select and mute controls. Because the remote is wired with a normal CAT5 cable, it is very easy to install.

On the output side, there is a line input selector and music level control per zone. A clear digital display makes it easier to monitor the functioning of the unit. Further, there are independent MIC-MIX level control and bass-treble control per zone.

The unit is 19” format and comes standard with removable brackets. The removable metal cover (included) protects your MIC-settings.
