Mixing Amplifiers

Apart

Mixing Amplifiers.


CONCEPT1

CONCEPT1

Product is not available for sale in the US or Canada

The CONCEPT1 is a stereo or two mono channel (2 x 80 watts @ 4 ohms) amplifier for small and medium-sized projects.

This 2-zone, integrated stereo amplifier can operate with one stereo zone, two volume-linked mono zones or two individual-volume mono zones. The unit can be controlled via RS232 what makes integration into your AV solution possible. The built-in limiters and system design guarantee a fail-safe solution 24 hours a day, 7 days a week.

To make the life of the end-user as easy as can be, the CONCEPT1 has user settings and installer settings. Only the absolute necessary features like volume, tone control and source selection can be adjusted by the end-user. The other advanced settings (operation mode settings, maximum music and mic volume, gain input adjustment, automatic loudness on/off, paging on/off per zone) can be configured and secured by the installer.

Product is not available for sale in the US or Canada

The CONCEPT1 is a stereo or two mono channel (2 x 80 watts @ 4 ohms) amplifier for small and medium-sized projects.

This 2-zone, integrated stereo amplifier can operate with one stereo zone, two volume-linked mono zones or two individual-volume mono zones. The unit can be controlled via RS232 what makes integration into your AV solution possible. The built-in limiters and system design guarantee a fail-safe solution 24 hours a day, 7 days a week.

To make the life of the end-user as easy as can be, the CONCEPT1 has user settings and installer settings. Only the absolute necessary features like volume, tone control and source selection can be adjusted by the end-user. The other advanced settings (operation mode settings, maximum music and mic volume, gain input adjustment, automatic loudness on/off, paging on/off per zone) can be configured and secured by the installer.


CONCEPT1T

CONCEPT1T

Product is not available for sale in the US or Canada

For a long time, installers worldwide have been unhappy with consumer electronics and they were looking for a professional integrated amplifier for use in commercial environments, boardrooms or small businesses designed for 24/7 operation. Therefore, we developed the CONCEPT1T, a stereo or two mono channel (2 x 60 watts in 100 volt) amplifier for small and medium-sized projects.

This CONCEPT1T 100-volt integrated mixing amplifier can operate with one stereo zone, two volume-linked zones or two individual-volume zones. The unit can be controlled via RS232 that makes integration into your AV solution possible. The built-in limiters and system design guarantee a failsafe solution 24 hours a day, 7 days a week.

To make the life of the end-user as easy as can be, the CONCEPT1T has user settings and installer settings. Only the absolute necessary features like volume, tone control and source selection can be adjusted by the end-user. The other advanced settings (operation mode settings, maximum music and mic volume, gain input adjustment, automatic loudness on/off, paging on/off per zone) can be configured and secured by the installer.



Product is not available for sale in the US or Canada

For a long time, installers worldwide have been unhappy with consumer electronics and they were looking for a professional integrated amplifier for use in commercial environments, boardrooms or small businesses designed for 24/7 operation. Therefore, we developed the CONCEPT1T, a stereo or two mono channel (2 x 60 watts in 100 volt) amplifier for small and medium-sized projects.

This CONCEPT1T 100-volt integrated mixing amplifier can operate with one stereo zone, two volume-linked zones or two individual-volume zones. The unit can be controlled via RS232 that makes integration into your AV solution possible. The built-in limiters and system design guarantee a failsafe solution 24 hours a day, 7 days a week.

To make the life of the end-user as easy as can be, the CONCEPT1T has user settings and installer settings. Only the absolute necessary features like volume, tone control and source selection can be adjusted by the end-user. The other advanced settings (operation mode settings, maximum music and mic volume, gain input adjustment, automatic loudness on/off, paging on/off per zone) can be configured and secured by the installer.




MA30

MA30

The MA30 comes in a compact 9.5” housing with 1 mic/line input and 2 stereo line, mono summed inputs.

The MA30 comes in a compact 9.5” housing with 1 mic/line input and 2 stereo line, mono summed inputs.


MA60

MA60

The compact 9.5” MA60 mixing amplifier has an unseen intuitive user-friendly interface and groundbreaking logical rear panel. The unit comes with 1 mic/line input and 2 stereo line, mono summed inputs. On the rear you can find smart left-to-right 4 level priority system for audio routing, an emergency input, paging mic with chime and a 24VDC override output. The design of the MA60 is a true redefinition of the mixing amplifier that goes back to the basics.

The compact 9.5” MA60 mixing amplifier has an unseen intuitive user-friendly interface and groundbreaking logical rear panel. The unit comes with 1 mic/line input and 2 stereo line, mono summed inputs. On the rear you can find smart left-to-right 4 level priority system for audio routing, an emergency input, paging mic with chime and a 24VDC override output. The design of the MA60 is a true redefinition of the mixing amplifier that goes back to the basics.


MA65

MA65

Product is not available for sale in the US or Canada

MA65 is probably the most compact and complete 65-watt 100 volt mixing amplifier. No doubt this product can be the heart of many small installation projects where priority or mixed microphone calls and background music dispersion are needed. On top of that this amplifier can also be used in mobile applications as the MA65 functions with 24 volt (truck, autobus, emergency power supply).

The MA65 has 4 inputs: 2 MIC, 1 MIC-Line and 1 line input. A two step priority system is standard: MIC1 can have voice activated priority (VOX) that mutes all other inputs. This VOX mute can be switched off via an internal jumper. The contact closure (via DIN5 on MIC1 or Euro block on MIC1-2) will activate the chime and will mute input 3 (MIC3/LINE3) and 4.

The pre-amp out, power-amp input allows you to insert extra signal processors or to link the signal to other power amplifiers. Furthermore, the MA65 is equipped with a bass – treble tone control, a record output and limiter circuit on the output to avoid clipping.

The MA65 has been built into a compact and sturdy metal housing. A 19” mounting bracket (Ref: MA35-19) is available as an option for rack mounting.

Product is not available for sale in the US or Canada

MA65 is probably the most compact and complete 65-watt 100 volt mixing amplifier. No doubt this product can be the heart of many small installation projects where priority or mixed microphone calls and background music dispersion are needed. On top of that this amplifier can also be used in mobile applications as the MA65 functions with 24 volt (truck, autobus, emergency power supply).

The MA65 has 4 inputs: 2 MIC, 1 MIC-Line and 1 line input. A two step priority system is standard: MIC1 can have voice activated priority (VOX) that mutes all other inputs. This VOX mute can be switched off via an internal jumper. The contact closure (via DIN5 on MIC1 or Euro block on MIC1-2) will activate the chime and will mute input 3 (MIC3/LINE3) and 4.

The pre-amp out, power-amp input allows you to insert extra signal processors or to link the signal to other power amplifiers. Furthermore, the MA65 is equipped with a bass – treble tone control, a record output and limiter circuit on the output to avoid clipping.

The MA65 has been built into a compact and sturdy metal housing. A 19” mounting bracket (Ref: MA35-19) is available as an option for rack mounting.


MA120

MA120

The revolutionary MA120 mixing amplifier offers the enduser an unseen cutting-edge design and ease-of-use. The ground-breaking intuitive front panel is clear and easy to use without any unnecessary bells and whistles. The volume control rotary on the front panel is prominent, illuminated, bigger and put in the forefront while the mic volume control is smaller and recessed.

This class-d mixing power amplifier offers 120 watts in 70 or 100 volt mode and comes with three mic inputs balanced, along with four stereo line, mono summed inputs.

The revolutionary MA120 mixing amplifier offers the enduser an unseen cutting-edge design and ease-of-use. The ground-breaking intuitive front panel is clear and easy to use without any unnecessary bells and whistles. The volume control rotary on the front panel is prominent, illuminated, bigger and put in the forefront while the mic volume control is smaller and recessed.

This class-d mixing power amplifier offers 120 watts in 70 or 100 volt mode and comes with three mic inputs balanced, along with four stereo line, mono summed inputs.


MA125

MA125

Product is not available for sale in the US or Canada

The MA125 is the most easy and universal 100-volt professional mixing amplifier for commercial and industrial applications. This amplifier is very intuitive to use because it has only the buttons available you really need. MA125 can drive 8 ohms or constant voltage loudspeakers.

4 microphone inputs with integrated speech filters, 4 selectable line inputs and one emergency line / telephone input are available where MIC input 1 is meant to be the main microphone paging input.  The MA125 allows you to have priority with your paging microphone as well as a seamless mix of your microphone with your sound source.

MA125 has a 3-level priority system where the emergency line / telephone input at the back have the highest priority. MIC1 has the second priority level and the third priority level can be activated by a dry contact at the back of the amplifier that mutes all background music inputs and activates the integrated chime. Further the MA125 is supplied with detachable 19” brackets.

When needed the signals mixed via the MA125 mixing amplifier can be recorded or distributed via the record output. You can even insert external signal processors or use the MA125 as a pre-amplifier in combination with an external power amplifier.

Product is not available for sale in the US or Canada

The MA125 is the most easy and universal 100-volt professional mixing amplifier for commercial and industrial applications. This amplifier is very intuitive to use because it has only the buttons available you really need. MA125 can drive 8 ohms or constant voltage loudspeakers.

4 microphone inputs with integrated speech filters, 4 selectable line inputs and one emergency line / telephone input are available where MIC input 1 is meant to be the main microphone paging input.  The MA125 allows you to have priority with your paging microphone as well as a seamless mix of your microphone with your sound source.

MA125 has a 3-level priority system where the emergency line / telephone input at the back have the highest priority. MIC1 has the second priority level and the third priority level can be activated by a dry contact at the back of the amplifier that mutes all background music inputs and activates the integrated chime. Further the MA125 is supplied with detachable 19” brackets.

When needed the signals mixed via the MA125 mixing amplifier can be recorded or distributed via the record output. You can even insert external signal processors or use the MA125 as a pre-amplifier in combination with an external power amplifier.


MA240

MA240

Product is not available for sale in the US or Canada

The revolutionary 19” MA240 mixing amplifier offers 240 watts in 70- or 100-volt mode and comes with 2 mic/line input and 4 stereo line, mono summed inputs. On the rear you can find smart left-to-right 4 level priority system for audio routing, an emergency input, paging mic with chime and a 24VDC override output.

Product is not available for sale in the US or Canada

The revolutionary 19” MA240 mixing amplifier offers 240 watts in 70- or 100-volt mode and comes with 2 mic/line input and 4 stereo line, mono summed inputs. On the rear you can find smart left-to-right 4 level priority system for audio routing, an emergency input, paging mic with chime and a 24VDC override output.


MA247

MA247

Product is not available for sale in the US or Canada

The MA247 is a 240 watts 6-zone 100-volt amplifier system that has been improved with 24 volt dedicated priority output per zone for more listening and operating comfort. Control the volume in 6 different zones, have a different sound source in one zone compared to all other zones or do selective paging in all zones without interrupting the music in the other zones. There is nothing like this on the market! It can be used stand-alone, or as the core of an expandable sound system.

Because the MA247 offers independent source selection for zones 1 and 2-6, it can be used as a multi-source zoning system. Zone 1 is a fully independent pre-amplified zone and allows the installer to use an external power amplifier to amplify it. It is especially useful for large areas that require many speakers, like factory production areas. This has the advantage that the installer can use the external amplifier to suit his power needs for that zone.

This amplifier is also available as amplifier with AM/FM tuner and built-in MP3 media player from SD-card or USB-stick (MA247MR).

Product is not available for sale in the US or Canada

The MA247 is a 240 watts 6-zone 100-volt amplifier system that has been improved with 24 volt dedicated priority output per zone for more listening and operating comfort. Control the volume in 6 different zones, have a different sound source in one zone compared to all other zones or do selective paging in all zones without interrupting the music in the other zones. There is nothing like this on the market! It can be used stand-alone, or as the core of an expandable sound system.

Because the MA247 offers independent source selection for zones 1 and 2-6, it can be used as a multi-source zoning system. Zone 1 is a fully independent pre-amplified zone and allows the installer to use an external power amplifier to amplify it. It is especially useful for large areas that require many speakers, like factory production areas. This has the advantage that the installer can use the external amplifier to suit his power needs for that zone.

This amplifier is also available as amplifier with AM/FM tuner and built-in MP3 media player from SD-card or USB-stick (MA247MR).


MA247MR

MA247MR

Product is not available for sale in the US or Canada

The MA247MR is a 240 watts 6-zone 100-volt amplifier system with an integrated FM/AM tuner and a media player that allows playing MP3-songs from a USB memory stick or SD-card. This mixing amplifier has been improved with 24-volt dedicated priority output per zone for more listening and operating comfort. Control the volume in 6 different zones, have a different sound source in one zone compared to all other zones or do selective paging in all zones without interrupting the music in the other zones. There is nothing like this on the market! It can be used stand-alone, or as the core of an expandable sound system.

Because the MA247MR offers independent source selection for zones 1 and 2-6, it can be used as a multi-source zoning system. Zone 1 is a fully independent pre-amplified zone and allows the installer to use an external power amplifier to amplify it. It is especially useful for large areas that require many speakers, like factory production areas. This has the advantage that the installer can use the external amplifier to suit his power needs for that zone.

This amplifier is also available as amplifier without tuner and media player (MA247).



Product is not available for sale in the US or Canada

The MA247MR is a 240 watts 6-zone 100-volt amplifier system with an integrated FM/AM tuner and a media player that allows playing MP3-songs from a USB memory stick or SD-card. This mixing amplifier has been improved with 24-volt dedicated priority output per zone for more listening and operating comfort. Control the volume in 6 different zones, have a different sound source in one zone compared to all other zones or do selective paging in all zones without interrupting the music in the other zones. There is nothing like this on the market! It can be used stand-alone, or as the core of an expandable sound system.

Because the MA247MR offers independent source selection for zones 1 and 2-6, it can be used as a multi-source zoning system. Zone 1 is a fully independent pre-amplified zone and allows the installer to use an external power amplifier to amplify it. It is especially useful for large areas that require many speakers, like factory production areas. This has the advantage that the installer can use the external amplifier to suit his power needs for that zone.

This amplifier is also available as amplifier without tuner and media player (MA247).
