Vocia POTS-1

Vocia POTS-1

The Vocia Telephone Paging adapter allows a direct connection of two or four analog telephone service (POTS) lines or POTS-based PBX telephone lines. The interface permits live, real-time paging using any page code within the Vocia system. POTS-1 supports Vocia regular and emergency messaging, and will also support page stacking and store-and-forward functionality.

  • Two or four POTS lines (POTS-1-2 or POTS-1-4)
  • Device monitoring
  • Power via dual 24V DC inputs (redundant inputs) power supply included
  • Software-configurable signal processing
  • Rack mountable (1RU)
  • Dual CobraNet® ports for redundant Ethernet connections
  • Rotary switches for device identification
  • IP30 compliant
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

The Vocia Telephone Paging adapter allows a direct connection of two or four analog telephone service (POTS) lines or POTS-based PBX telephone lines. The interface permits live, real-time paging using any page code within the Vocia system. POTS-1 supports Vocia regular and emergency messaging, and will also support page stacking and store-and-forward functionality.

  • Two or four POTS lines (POTS-1-2 or POTS-1-4)
  • Device monitoring
  • Power via dual 24V DC inputs (redundant inputs) power supply included
  • Software-configurable signal processing
  • Rack mountable (1RU)
  • Dual CobraNet® ports for redundant Ethernet connections
  • Rotary switches for device identification
  • IP30 compliant
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

Vocia PSKIT-1

Vocia PSKIT-1

The PSKIT-1 is a standalone Paging Station Kit designed to allow for direct connection to third-party equipment such as fireman’s microphone stations or custom designed fire panels. The PSKIT-1 features embedded DSP and on-board memory to support standard and advanced public address and mass notification functionalities. The PSKIT-1 can store 999 user-configurable Page Codes. Additionally, all device-specific configuration information is stored locally, which means the PSKIT-1 does not rely on a centralized controller for processing and page routing.

  • Up to 999 user-configurable Page Codes
  • 8 priority levels: 4 regular priority levels, 4 emergency priority levels
  • Local storage of default and/or custom preambles
  • Built-in store and forward functionality
  • Microphone and Push-to-Talk (PTT) input
  • Dual/Redundant Powering (PoE, 24V DC)
  • 12 General Purpose Inputs
  • 3 General Purpose Outputs
  • Rotary ID switches for unit identification
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

The PSKIT-1 is a standalone Paging Station Kit designed to allow for direct connection to third-party equipment such as fireman’s microphone stations or custom designed fire panels. The PSKIT-1 features embedded DSP and on-board memory to support standard and advanced public address and mass notification functionalities. The PSKIT-1 can store 999 user-configurable Page Codes. Additionally, all device-specific configuration information is stored locally, which means the PSKIT-1 does not rely on a centralized controller for processing and page routing.

  • Up to 999 user-configurable Page Codes
  • 8 priority levels: 4 regular priority levels, 4 emergency priority levels
  • Local storage of default and/or custom preambles
  • Built-in store and forward functionality
  • Microphone and Push-to-Talk (PTT) input
  • Dual/Redundant Powering (PoE, 24V DC)
  • 12 General Purpose Inputs
  • 3 General Purpose Outputs
  • Rotary ID switches for unit identification
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

Vocia VI-6

Vocia VI-6

The VI-6 is a networked audio input expansion device allowing the user to add up to six channels of background music or user-defined audio to a Vocia system. As part of the Vocia system, the VI-6 meets paging requirements for facilities of all sizes.

  • 4 sets of dual RCA connectors, plus terminal block connectors for line-level inputs
  • 4 control inputs and 4 control outputs
  • 2 microphone/line inputs with phantom power
  • PoE (Power over Ethernet)
  • Software-configurable local audio signal processing including gain, filters, and compressor/limiter
  • Rotary switches for unit identification
  • CobraNet audio/control with dynamic use of available bundles
  • Status LEDs to indicate signal and clip
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

The VI-6 is a networked audio input expansion device allowing the user to add up to six channels of background music or user-defined audio to a Vocia system. As part of the Vocia system, the VI-6 meets paging requirements for facilities of all sizes.

  • 4 sets of dual RCA connectors, plus terminal block connectors for line-level inputs
  • 4 control inputs and 4 control outputs
  • 2 microphone/line inputs with phantom power
  • PoE (Power over Ethernet)
  • Software-configurable local audio signal processing including gain, filters, and compressor/limiter
  • Rotary switches for unit identification
  • CobraNet audio/control with dynamic use of available bundles
  • Status LEDs to indicate signal and clip
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

Vocia VI-8

Vocia VI-8

The Vocia Input 8 (VI-8) is designed to facilitate live audio paging from user sources to emergency and non-emergency zones in a Vocia system. The VI-8 will allow direct paging access from eight sources via analog mic/line level inputs or CobraNet digital audio connections. Nine logic inputs can be assigned to various Vocia control events including paging control. A logic output and four relay outputs can be assigned to control events. The logic output may be used to report status from one or several daisy-chained VI-8s to an external system. The logic inputs and output are monitored.

  • 8 analog mic/line level or CobraNet inputs
  • 1 logic and 4 relay control outputs
  • 8 logic inputs
  • Device status monitoring via control logic input and output
  • Power via dual 24V DC inputs (redundant inputs) power supply included
  • Software-configurable signal processing including volume control, filters, and compressor/limiting
  • Rack mountable (1RU)
  • Dual CobraNet ports for redundant Ethernet connections
  • Device and logic I/O status monitoring
  • Rotary switches for device identification
  • IP30 compliant
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

The Vocia Input 8 (VI-8) is designed to facilitate live audio paging from user sources to emergency and non-emergency zones in a Vocia system. The VI-8 will allow direct paging access from eight sources via analog mic/line level inputs or CobraNet digital audio connections. Nine logic inputs can be assigned to various Vocia control events including paging control. A logic output and four relay outputs can be assigned to control events. The logic output may be used to report status from one or several daisy-chained VI-8s to an external system. The logic inputs and output are monitored.

  • 8 analog mic/line level or CobraNet inputs
  • 1 logic and 4 relay control outputs
  • 8 logic inputs
  • Device status monitoring via control logic input and output
  • Power via dual 24V DC inputs (redundant inputs) power supply included
  • Software-configurable signal processing including volume control, filters, and compressor/limiting
  • Rack mountable (1RU)
  • Dual CobraNet ports for redundant Ethernet connections
  • Device and logic I/O status monitoring
  • Rotary switches for device identification
  • IP30 compliant
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

Vocia VOIP-1

Vocia VOIP-1

The Vocia Voice over IP Interface (VoIP-1) acts as a SIP end point allowing a direct connection to an existing VoIP call manager. The interface permits live, real-time paging using any page code within a Vocia system. The VoIP-1 supports Vocia regular and emergency messaging, and will also support page stacking and store-and-forward functionality.

  • Two or four VoIP lines (VOIP-1-2 or VOIP-1-4)
  • Multiple codec support
  • Device monitoring
  • Power via dual 24V DC inputs (redundant inputs) power supply included
  • Software-configurable signal processing
  • Rack mountable (1RU)
  • Dual CobraNet ports for redundant Ethernet connections
  • Rotary switches for device identification
  • IP30 compliant
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

The Vocia Voice over IP Interface (VoIP-1) acts as a SIP end point allowing a direct connection to an existing VoIP call manager. The interface permits live, real-time paging using any page code within a Vocia system. The VoIP-1 supports Vocia regular and emergency messaging, and will also support page stacking and store-and-forward functionality.

  • Two or four VoIP lines (VOIP-1-2 or VOIP-1-4)
  • Multiple codec support
  • Device monitoring
  • Power via dual 24V DC inputs (redundant inputs) power supply included
  • Software-configurable signal processing
  • Rack mountable (1RU)
  • Dual CobraNet ports for redundant Ethernet connections
  • Rotary switches for device identification
  • IP30 compliant
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

Vocia VPSI-1

Vocia VPSI-1

The VPSI-1 device is designed to allow third party microphones and LED indicators to interface as slave devices to the Vocia Wall Stations (WS-4/10, EWS-4/10) and Desk Stations (DS-4/10) series microphones and to the Vocia Input 6 (VI-6) device for paging via the Paging Ports. The VPSI-1 can also facilitate third party microphones and control system interfacing with Vocia Wall and Desk Stations. The host Paging Station must be configured for ‘Remote control’ mode within the software.

  • Slave interface to Vocia Paging Stations and VI-6 device
  • Visual feedback of Paging and Zone status
  • Suitable for surface mounting
  • Audio, Power and Control over a single Ethernet cable (PoE)
  • IP30 Compliant
  • Power is provided by the host device
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty

The VPSI-1 device is designed to allow third party microphones and LED indicators to interface as slave devices to the Vocia Wall Stations (WS-4/10, EWS-4/10) and Desk Stations (DS-4/10) series microphones and to the Vocia Input 6 (VI-6) device for paging via the Paging Ports. The VPSI-1 can also facilitate third party microphones and control system interfacing with Vocia Wall and Desk Stations. The host Paging Station must be configured for ‘Remote control’ mode within the software.

  • Slave interface to Vocia Paging Stations and VI-6 device
  • Visual feedback of Paging and Zone status
  • Suitable for surface mounting
  • Audio, Power and Control over a single Ethernet cable (PoE)
  • IP30 Compliant
  • Power is provided by the host device
  • CE marked and RoHS compliant
  • Covered by Biamp Systems’ five-year warranty
