Vocia CI-1
Vocia CI-1
The CI-1 Control Interface is a companion product to the Vocia LSI-16 Life Safety Interface. It facilitates necessary connections with the LSI-16/LSI-16e to meet EN 54-16 standards.
- High reliability switches for Local Sounder Silence, System Test, and System Fault Reset
- High level sounder for Fault/Alarm warning
- Dual 24V DC power summing with power loss fault connection
- Provides terminating resistors for Alarm and Fault Inputs
- Provides terminating resistors for any unused monitored outputs
- Current limited reference voltage output
- Rack mountable (1RU)
- EN 54-16 certified, EN 60849 and AS 60849 verified, CE marked, and RoHS compliant
- Covered by Biamp Systems’ five-year warranty
The CI-1 Control Interface is a companion product to the Vocia LSI-16 Life Safety Interface. It facilitates necessary connections with the LSI-16/LSI-16e to meet EN 54-16 standards.
- High reliability switches for Local Sounder Silence, System Test, and System Fault Reset
- High level sounder for Fault/Alarm warning
- Dual 24V DC power summing with power loss fault connection
- Provides terminating resistors for Alarm and Fault Inputs
- Provides terminating resistors for any unused monitored outputs
- Current limited reference voltage output
- Rack mountable (1RU)
- EN 54-16 certified, EN 60849 and AS 60849 verified, CE marked, and RoHS compliant
- Covered by Biamp Systems’ five-year warranty
Additional Information
Vocia LSI-16
Vocia LSI-16
The LSI-16 serves as an emergency interface between a Vocia system and emergency/fire alarm systems. While typically powered from a certified 24V DC source, it can also utilize Power over Ethernet (PoE).
- Parallel I/O ports for direct interface with fire alarm and emergency equipment
- 8 monitored I/O and 8 control inputs
- Redundant network connection and power supply options
- Power and data over a single Ethernet cable
- Local storage of configuration data
- Rotary switches for unit identification
- Accepts the Interface Module 16 (IM-16) for 16 additional general purpose inputs
- Status LEDs
- Rack mountable (1RU)
- Up to 4 discrete emergency inputs
- Up to 500 virtual inputs via RS-232 port or Ethernet
- RoHS compliant
- Covered by Biamp Systems’ five-year warranty
The LSI-16 serves as an emergency interface between a Vocia system and emergency/fire alarm systems. While typically powered from a certified 24V DC source, it can also utilize Power over Ethernet (PoE).
- Parallel I/O ports for direct interface with fire alarm and emergency equipment
- 8 monitored I/O and 8 control inputs
- Redundant network connection and power supply options
- Power and data over a single Ethernet cable
- Local storage of configuration data
- Rotary switches for unit identification
- Accepts the Interface Module 16 (IM-16) for 16 additional general purpose inputs
- Status LEDs
- Rack mountable (1RU)
- Up to 4 discrete emergency inputs
- Up to 500 virtual inputs via RS-232 port or Ethernet
- RoHS compliant
- Covered by Biamp Systems’ five-year warranty
Additional Information
Vocia LSI-16e
Vocia LSI-16e
The LSI-16e is an enhancement to the LSI-16 adding 16 additional control inputs and EN 54-16 certification. The LSI-16e serves as an enhanced emergency interface between a Vocia system and emergency/fire alarm systems. While typically powered from a certified 24V DC source, it can also utilize Power over Ethernet (PoE).
- Parallel I/O ports for direct interface with fire alarm and emergency equipment
- 8 monitored I/O and 8 control inputs
- Redundant network connection and power supply options
- Power and data over a single Ethernet cable
- Local storage of configuration data
- Rotary switches for unit identification
- Up to 4 discrete emergency inputs
- 16 additional general purpose inputs can be programmed to play emergency message, enable zone reset or zone silence; maximum 10 inputs can be assigned per emergency zone
- Each general purpose input can be programmed as TTL, high range, or monitored high range
- General purpose inputs allow monitoring for short to ground and open circuit
- Up to 500 virtual inputs via RS-232 or Ethernet
- Provides system heath monitoring via RS-232 or Ethernet
- Status LEDs
- Rack mountable (1RU)
- EN 54-16 certified, EN 60849 and AS 60849 verified, CE marked, and RoHS compliant
- Covered by Biamp Systems’ five-year warranty
The LSI-16e is an enhancement to the LSI-16 adding 16 additional control inputs and EN 54-16 certification. The LSI-16e serves as an enhanced emergency interface between a Vocia system and emergency/fire alarm systems. While typically powered from a certified 24V DC source, it can also utilize Power over Ethernet (PoE).
- Parallel I/O ports for direct interface with fire alarm and emergency equipment
- 8 monitored I/O and 8 control inputs
- Redundant network connection and power supply options
- Power and data over a single Ethernet cable
- Local storage of configuration data
- Rotary switches for unit identification
- Up to 4 discrete emergency inputs
- 16 additional general purpose inputs can be programmed to play emergency message, enable zone reset or zone silence; maximum 10 inputs can be assigned per emergency zone
- Each general purpose input can be programmed as TTL, high range, or monitored high range
- General purpose inputs allow monitoring for short to ground and open circuit
- Up to 500 virtual inputs via RS-232 or Ethernet
- Provides system heath monitoring via RS-232 or Ethernet
- Status LEDs
- Rack mountable (1RU)
- EN 54-16 certified, EN 60849 and AS 60849 verified, CE marked, and RoHS compliant
- Covered by Biamp Systems’ five-year warranty
Additional Information
Interface Modules.
The IM-16 Interface Module physically fits into the LSI-16 option slot. The IM-16 offers an additional 16 control inputs that can be configured in the Vocia software as alarm, fault, or reset inputs.
- 16 control inputs
- Each input can be programmed as TTL, high range, or monitored high range
- Monitoring for short-to-ground, open circuit, and over voltage
- Suitable for the LSI-16 option slot
- Power, processing, and indication by the LSI-16
- Cable connections via pluggable screw terminal blocks
- EN 54-16 certified, EN 60849 and AS 60849 verified, and RoHS compliant
- Covered by Biamp Systems’ five-year warranty
